Main Function Of HK2005 3D VSR



Main function of HK2005 3D VSR

The color LCD screen display the curves and data dynamically,the aging process and the curve trend are clear at a glance.

Determining the process parameters suitable or not and giving the amendments to the program,to realize the man-machine dialogue prompt function.

Full-automatic operation to prevent the personal factor(with both manual and semi-automatic).

Adopting the technology of double-loop design and strong anti-jamming capability of plus-width modulation technology.

Dynamic tracking function can ensure vibration treatment is always in the standard of sub-resonance region.

The motor only started once during the whole vibration aging process,it can save 1/2 auxiliary testing time.

Selecting the excitation freqency to aging as per the optimized process according to the advanced spectrum analysis technology.

Printing the overlapping curves of a-n and a-t and data comparison automatically,In order to test them and make permanent presarvation.

This series is suitable for the major components demanded vibrating aging of eliminating stress strictly.

Achieving three-dimensional vibration and measuremeat on the workpiece,improve the level of stress relief.

The wireless remote control over a long distance and whole point.

Powerful version 3.0 software control technology.

Regular and fixed-speed printing.

Ultra-safe circuit designing.

Main specification of HK2005 3D VSR equipment

Item / model HK2005K1 HK2005K2 HK2005K3 HK2005K4 HK2005K5
Max centrifugal(KN) 10 15 30 40 50
Speed(rpm) 1000-10000 1000-8000 1000-8000 1000-8000 1000-8000
Max treat weight(T) 2.5 10 50 100 500
Rated power(KW) 0.6 1.2 1.5 2.2 3.6
Rated voltage(V) 220V/50Hz 220V/50Hz 220V/50Hz 220V/50Hz 220V/50Hz
Steady speed precision(r/min) ±1 ±1 ±1 ±1 ±1
Acceleration(m/s2) 0~199.9 0~199.9 0~199.9 0~199.9 0~199.9
Time range(min) 0~40 0~40 0~40 0~40 0~40
Color screen Dynamic display a-n,a-t data of surve and specification on-line
Printing a-n,a-t surves,specification data and specification contrast
Dynamic tracking function According to the variation of parameters of workpiece adjust the aging parameters automatically in the aging process
